IBO NOVA 25-40/180 pump

Head: 4m

Flow: 50 L/min

Motor: 5-22 W

Voltage: 230v

Connector diameter: 1½" x 1"

Connector spacing: 180mm

Energy-saving electronic circulation pump, which meet the requirements of A-rated pumps.

The energy efficiency index of the NOVA pumps is EEI ≤ 0,20.

This pump is equipped with a differential pressure controller which automatically and continuously adjusts the pump performance to meet the actual needs
of the system. The pump set includes a set of screw connections.

The pump has 8 operating modes:
• AUTO (factory default) - high to low proportional pressure characteristic
curve
• BL1 / BL2 - Proportional pressure curves
• HD1 / HD2 - Constant pressure curves
• HS1/HS2/HS3 - Constant speed curves

Application:
The NOVA series circulation pump is best suited for the following systems:
Equithermic heating systems with variable flow:
• Heating systems with variable pipeline temperature
• Heating systems with night mode
• Air conditioning systems
• Industrial circulation systems
• Home central heating systems and home hot water systems

Electrical supply:  1 × 230 V +6%/-10%, 50 Hz

IP: 44

Insulation class: F

Maximum ambient relative humidity: ≤ 95%

Maximum pressure in the central heating system: 1 Mpa

Minimum inlet suction pressure depending on heating medium temperature
Medium temperature
≤ 85°C  - 0,005 MPa
≤ 90°C - 0,028 MPa
≤ 95°C - 0,050 MPa

EMC compliance: EN61000-6-1; EN61000-6-3

Very silent work: <43dB (A)

Allowable ambient temperature: 0~+40°C

Maximum heat of pump surface: ≤ 110°C

Fluid temperature range:  2~+95°C

Weight: 2,8 kg

Warranty: 24 months

Product color on pictures may be different than in reality.
